Ableton.js

Ableton.js lets you control Ableton 11 or later using Node.js, Deno, or a browser. It tries to cover as many functions as possible.

This package is still a work-in-progress. My goal is to expose all of Ableton's MIDI Remote Script functions to TypeScript. If you'd like to contribute, please feel free to open a PR.

Sponsored Message

I've used Ableton.js to build a setlist manager called AbleSet. AbleSet allows you to easily manage and control your Ableton setlists from any device, re-order songs and add notes to them, and get an overview of the current state of your set.

Prerequisites

Ableton.js requires Ableton Live 11 or later.

To use this library, you'll need to install and activate the MIDI Remote Script in Ableton.js. To do that, copy the midi-script folder of this repo to Ableton's Remote Scripts folder and rename it to AbletonJS. The MIDI Remote Scripts folder is usually located at ~/Music/Ableton/User Library/Remote Scripts

After starting Ableton Live, add the script to your list of control surfaces:

The Remote Script opens a WebSocket server on 127.0.0.1:39031 by default. You can change the bind address and port in midi-script/Config.py (WEBSOCKET_HOST / WEBSOCKET_PORT). The JS client must use the same port (new Ableton({ port })).

To require a password, set PASSWORD in Config.py to a string and pass the same value to new Ableton({ password }). Auth is off when PASSWORD is None or empty. When enabled, the plugin sends a per-connection salt and the client authenticates with HMAC-SHA256 so the password itself is not sent in plaintext. The WebSocket is still unencrypted (ws://) after login, so I'd prefer binding to loopback if possible.

If you've forked this project on macOS, you can also use yarn to do that for you. Running yarn ableton11:start or yarn ableton12:start (depending on your app version) will copy the midi-script folder, open Ableton and show a stream of log messages until you kill it.

Using Ableton.js

This library exposes an Ableton class which lets you control the entire application. You can instantiate it once and use TS to explore available features.

Example:

import { Ableton } from "ableton-js";

// Log all messages to the console
const ableton = new Ableton({ logger: console });

const test = async () => {
  // Establishes a connection with Live
  await ableton.start();

  // Observe the current playback state and tempo
  ableton.song.addListener("is_playing", (p) => console.log("Playing:", p));
  ableton.song.addListener("tempo", (t) => console.log("Tempo:", t));

  // Get the current tempo
  const tempo = await ableton.song.get("tempo");
  console.log("Current tempo:", tempo);

  // Set the tempo
  await ableton.song.set("tempo", 85);

  // Commands started in the same tick are sent together
  const tracks = await ableton.song.get("tracks");
  await Promise.all(
    tracks.map((t) => t.addListener("name", (n) => console.log(t.raw.id, n))),
  );
};

test();

Ableton.js also serves files located in midi-script/static on the same port as the WebSocket, so you can host your own web app from within Live. By default, this folder contains a bundled version of Ableton.js and a simple index.html file that allows you to use the browser's console to try out the API.

Events

There are a few events you can use to get more under-the-hood insights:

// A connection to Ableton is established
ab.on("connect", (e) => console.log("Connect", e));

// Connection to Ableton was lost,
// also happens when you load a new project
ab.on("disconnect", (e) => console.log("Disconnect", e));

// A raw message was received from Ableton
ab.on("message", (m) => console.log("Message:", m));

// A received message could not be parsed
ab.on("error", (e) => console.error("Error:", e));

// Fires on every response with the current ping
ab.on("ping", (ping) => console.log("Ping:", ping, "ms"));

Protocol

Ableton.js uses a WebSocket (ws://127.0.0.1:39031 by default) to talk to the MIDI Remote Script. Each message is a JSON text frame containing required data and a UUID so request and response can be associated with each other.

The Remote Script is the server and supports connections from multiple clients. Command replies (result / error) and property listener updates are sent only to the client that issued the command or subscribed. Removing a listener, or disconnecting, drops that client's subscriptions only. Live still uses a single listener per property until the last subscriber leaves.

Caching

Certain props are cached on the client to reduce repeated payloads. To do this, the Ableton plugin generates an MD5 hash of the prop, called ETag, and sends it to the client along with the data.

The client stores both the ETag and the data in an LRU cache and sends the latest stored ETag to the plugin the next time the same prop is requested. If the data still matches the ETag, the plugin responds with a placeholder object and the client returns the cached data.

Commands

Every request is an envelope with one or more commands. Commands started in the same JavaScript tick (for example via Promise.all) are automatically combined into a single WebSocket round-trip.

{
  "uuid": "1", // Envelope id
  "commands": [
    {
      "ns": "song", // The command namespace
      "nsid": null, // The namespace id, for example to address a specific track or device
      "name": "get_prop", // Command name
      "args": { "prop": "current_song_time" }, // Command arguments
      "etag": "4e0794e44c7eb58bdbbbf7268e8237b4", // MD5 hash of the data if it might be cached locally
      "cache": true // If this is true, the plugin will calculate an etag and return a placeholder if it matches the provided one
    }
  ]
}

The MIDI Script answers with a JSON object looking like this. data is always an array with one result per command:

{
  "data": [{ "ok": true, "data": 0.0 }], // Per-command results
  "event": "result", // This can be 'result' or 'error'
  "uuid": "1" // The same UUID that was used to send the envelope
}

A failed command looks like { "ok": false, "error": "..." } in its slot. Other commands in the same envelope still run. A top-level event: "error" means the whole envelope failed (for example auth or a malformed payload).

If you're getting a cached prop, the per-command data could look like this:

{
  "data": [
    {
      "ok": true,
      "data": { "data": 0.0, "etag": "4e0794e44c7eb58bdbbbf7268e8237b4" }
    }
  ],
  "event": "result",
  "uuid": "1"
}

Or, if the data hasn't changed, the per-command data looks like this:

{
  "data": [{ "ok": true, "data": { "__cached": true } }],
  "event": "result",
  "uuid": "1"
}

Events

To attach an event listener to a specific property, the client sends a command:

{
  "uuid": "1", // Envelope id
  "commands": [
    {
      "ns": "song",
      "name": "add_listener",
      "args": {
        "prop": "current_song_time",
        "eventId": "2"
      }
    }
  ]
}

The MIDI Script answers with a JSON object looking like this to confirm that the listener has been attached:

{
  "data": [{ "ok": true, "data": "2" }],
  "event": "result",
  "uuid": "1"
}

From now on, when the observed property changes, the MIDI Script sends an event object (not wrapped in a commands envelope):

{
  "data": 68.0, // The new value, can be any JSON-compatible type
  "event": "2", // The event id
  "uuid": null // Is always null and may be removed in future versions
}

Note that for some values, this event is emitted multiple times per second. 20-30 updates per second are not unusual.

Connection Events

The MIDI Script sends events when it starts and when it shuts down. These look like this:

{
  "data": { "port": 39031 },
  "event": "connect", // Can be connect or disconnect
  "uuid": null
}

disconnect still sends "data": null.

When you open a new Project in Ableton, the script will shut down and start again.

When Ableton.js receives a disconnect event, it clears all current event listeners and pending commands. It is usually a good idea to attach all event listeners and get properties each time the connect event is emitted.

Findings

In this section, I'll note interesting pieces of information related to Ableton's Python framework that I stumble upon during the development of this library.

• It seems like Ableton's listener to output_meter_level doesn't quite work as well as expected, hanging every few 100ms. Listening to output_meter_left or output_meter_right works better. See Issue #4
• The playing_status listener of clip slots never fires in Ableton. See Issue #25

Contributing

If you'd like to add features to this project or submit a bugfix, please feel free to open a pull request. Before committing changes to any of the TypeScript files, please run yarn format to format the code using Prettier.
